How to install window security bars

Complete DIY installation guide, from measuring to final tightening in 15–30 minutes. Works for apartments, houses, wood, vinyl, and masonry walls.

  • 15–30 min per window
  • Standard drill only
  • All hardware included
  • Apartment-friendly

Updated November 2026 · 8 min read · Security Window Bars

Watch it first: one video per model

Model A · in the frame · 1:04
Model B · on the wall · 1:08
Model A/EXIT · opens from inside · 1:08

Illustrative 3D animation of the real installation steps.

The most common installation mistakeis measuring the glass instead of the clear opening. It's the most common sizing error we see.

This guide walks through all 10 installation steps in the order that prevents it. Read the measurement section carefully before touching the box.

The entire installation takes 15–30 minutes per window. If it's taking longer, you're at a step where something is slightly off, and it's always faster to stop and recheck.

Quick answer

How long does window bar installation take? For SWB bars on a standard wood or vinyl frame window: 15–30 minutes per window, including measuring, drilling 4 holes, and final verification. Masonry walls with a hammer drill add 10–15 minutes per window. Tools needed: standard drill, measuring tape, pencil, bubble level. No special skills or prior installation experience required.

Tools required by wall type

Wall / frame typeDrill bitAnchor typeTime / window
Wood frameStandard wood bit (included)Wood screw (included)15–20 min
Vinyl frameStandard wood bit (included)Wood screw (included)15–20 min
Drywall / stucco3/16" masonry bitPlastic wall anchor20–25 min
Concrete / brick (Model B)Carbide-tipped masonry bitHammer-set anchor (included with B)25–30 min
Metal window frameMetal/HSS bit (not included)Self-tapping screw20–25 min
Security Window Bars

SWB's in-house compliance and product team. Every code reference and specification on this page is sourced and linked.

Before you start

What you need

Tools (not included)

  • Standard power drill (12V or higher)
  • Measuring tape
  • Pencil or chalk marker
  • Bubble level
  • Screwdriver (flat + Phillips)
  • Safety glasses

Included in the box

  • SWB bar module(s)
  • Mounting brackets (4 per module)
  • Screws + wall anchors
  • Drill bit template card
  • Installation guide (printed)
  • Level bubble sticker
Step-by-step installation

10 steps to install

  1. Measuring a window opening with a tape measure for security bar installation

    Measure Your Window Opening

    Measure the clear opening — jamb to jamb for width, sill to header for height. Write both dimensions down. Do NOT measure the glass or frame; measure the empty opening space. Double-check with a second measurement.

    Tip: Standard windows: 24"–36" wide. Wide windows: 37"–60". Use our Module Calculator to determine how many modules you need.

  2. Window security bar hardware components laid out: bars labeled A and B with screws

    Identify Your Hardware Components

    Open the box and lay out all components: vertical bar sections (A), horizontal rail connectors (B), mounting brackets, anchors, and screws. Verify all parts are present against the included checklist before starting.

    Tip: Missing a part? Don't proceed. Contact SWB support before installing — installing with substitute hardware voids the warranty.

  3. Window security bar positioned in window opening showing side profile depth

    Position Bar in the Opening

    Lift the assembled bar and slide it into the window opening. Check the fit from the side — the bar should sit flush with the wall plane, with even clearance on both sides. This is a dry fit only; do not attach hardware yet.

    Tip: If the bar doesn't slide in cleanly, do NOT force it. Collapse the telescoping sections slightly and readjust. Forced insertion bends the frame.

  4. Marking mounting hole positions on window frame with four indicator points

    Mark Your Mounting Points

    Hold the bar level in the opening and use a pencil to mark all 4 mounting hole locations (2 top, 2 bottom). Use the drill template card included in the box for precise spacing. Mark center of each bracket hole, not the edge.

    Tip: Use a level to verify the bar is perfectly horizontal before marking. A tilted bar is visible and difficult to correct after drilling.

  5. Front view of horizontal window security bar rails showing alignment

    Align the Horizontal Rails

    Before drilling, hold the assembled bar flat against the mounting surface and verify all horizontal rails are perfectly parallel to the windowsill. Minor adjustments now prevent visible misalignment once installed.

    Tip: A 2-foot level across the horizontal rails confirms alignment faster than eyeballing. Both outer rails must be the same distance from the sill.

  6. Bottom anchor base plates positioned with three vertical bars passing through

    Attach the Anchor Base Plates

    Position each anchor plate over its marked location. The plate should sit flat on the sill or frame face with zero rocking. Pre-thread one screw by hand to hold position while you verify alignment before final tightening.

    Tip: On uneven surfaces, use the included shim kit to level the base plate. A tilted base plate creates shear stress on the anchor bolts over time.

  7. Anchor base plate installed on window sill with bars secured through plate

    Drill and Insert Anchors

    Drill at the marked points to the depth indicated on the template card. For wood/vinyl: use a standard wood bit. For masonry/concrete: use the included carbide-tipped masonry bit at slow speed. Tap anchors flush with a hammer.

    Tip: Anchors must be flush or slightly below surface — never protruding. A raised anchor prevents the bracket from sitting flat, weakening the hold.

  8. Window security bar mounting bracket secured to window sill anchor plate

    Mount and Secure the Bar

    Position the bar brackets over the anchors and drive all screws until snug. Do not overtighten — hand-tight plus 1/4 turn is sufficient. Vinyl frames especially: snug is enough, over-torquing cracks the frame.

    Tip: A second person holding the bar while you drive screws makes this much easier. Alternatively, use painter's tape to temporarily hold the bar in position.

  9. Window bars installed with adjustment indicator showing telescoping height setting

    Adjust Telescoping Height

    With the bar mounted at the bottom, extend the telescoping upper section until the top bracket reaches the header mounting marks. Lock the telescoping section per the included instructions, then attach the top bracket.

    Tip: The telescoping section should feel solid with no play when locked. If it moves, the locking collar is not fully seated — rotate and click again.

  10. Final installed window security bars viewed from outside, installation complete

    Verify and Test the Installation

    Use a level to confirm the bar is vertical and horizontal. Grip the bar firmly and push/pull in all directions — zero flex or movement is acceptable. For Model A/EXIT, test the quick-release mechanism 3 times to confirm smooth operation.

    Tip: A properly installed bar should not shift or rattle. If the bar moves at all, check anchor depth and retighten screws before calling it done.

Mount type

Frame mount vs. wall mount

SWB offers two primary mounting approaches:

Frame mount (Model A)

Brackets attach directly to the window frame (wood or vinyl). Faster installation, cleaner look, great for apartments. On vinyl frames the hold is limited by the frame itself, so wall mount is the stronger choice where you can use it.

Wall mount (Models A & B)

Brackets anchor into the surrounding wall. Stronger hold, especially on masonry. Required for concrete or stucco walls where frame mounting isn't feasible.

Avoid these

Common mistakes

  • Measuring the glass, not the opening

    Measure the clear opening, jamb to jamb. Measuring the glass instead is the most common sizing error.

  • Skipping the level

    A crooked bar is obvious from outside and reduces security effectiveness.

  • Wrong anchor for wall type

    Drywall anchors in masonry will fail. Match the anchor to the substrate.

  • Over-tightening on vinyl

    Vinyl compresses; overtightening cracks frames. Snug is sufficient.

  • Not testing the quick-release

    For Model A/EXIT, test the mechanism before considering installation complete.

  • No landlord approval in apartments

    Always get written permission before installing in a rental unit.

Security Window Bars

SWB's in-house compliance and product team. Every code reference and specification on this page is sourced and linked.

Security Window Bars writes and reviews the technical content on this site. Every code reference is cited to its source (IBC, IRC, NFPA or the applicable state or city code) so you can verify it yourself. Final compliance is determined by your local authority having jurisdiction (AHJ).

Installation FAQ

Do I need a professional to install window security bars?

No. SWB bars are engineered for DIY installation in 15–30 minutes per window. You need a standard drill, measuring tape, pencil, and bubble level — all commonly owned household tools. All mounting hardware and anchors are included.

What type of drill bit do I need for masonry installation?

For masonry, concrete, or stucco walls, use carbide-tipped masonry drill bits in the sizes specified in your SWB installation guide (typically 3/16" and 1/4"). Model B includes masonry-specific anchors pre-matched to these sizes.

How do I install on vinyl window frames without cracking them?

Use the frame-mount hardware included with Model A. Drill at slow speed and apply light, steady pressure. Never overtighten — snug is sufficient. Vinyl compresses slightly but won't crack with proper technique.

How high should window bars be mounted?

Bars should span the full height of the clear opening. The bottom rail should sit 1" above the sill; the top rail should be 1" below the header. Adjust the telescoping height to match your specific window.

Can I install SWB bars on a second-floor window?

Yes. Installation is identical to ground floor — the process is the same regardless of floor level. Use proper ladder safety if working at height. Consider adding a safety rope to prevent dropping the bar during installation.

Can I install window bars in an apartment?

Yes, with your landlord's permission. SWB bars use frame-mount brackets that leave minimal marks. Many landlords approve them because they improve building security. Always check your lease first and document the installation with photos.
