Security Grid for Windows: The Smart Defense Matrix

Security Grid for Windows: The Smart Defense Matrix | Security WB

Adaptive Security Series

SECURITY GRID FOR WINDOWS

The intersection of visibility and impregnability. Unlike traditional bars, a security grid creates a matrix of protection that distributes force evenly across the entire window frame.

View Systems Specs Sheet

The Grid Advantage

While vertical bars have weak points (usually in the horizontal spread), a security grid for windows uses a cross-hatch or mesh pattern. This geometry creates hundreds of small "cells" rather than a few large gaps.

Force Distribution

Impact energy is dispersed across the X and Y axis simultaneously, making it twice as hard to bend with a crowbar.

Smaller Gaps

Grid patterns typically have openings smaller than 4 inches, preventing not just human entry, but also hand-reach to unlock latches.

Modern Look

Grids mimic the "divided light" panes of modern windows, often disappearing into the visual background of the home.

Grid Configurations

Not all grids are created equal. At Security WB, we classify them by their node connections (where the bars intersect).

Grid Type	Connection Method	Security Rating
Woven Mesh	Interlaced Wires	High (Flexible)
Welded Grid	Fusion at every cross	Maximum (Rigid)
Diamond Plate	Expanded Metal	Industrial/Max
Riveted Grid	Mechanical Fasteners	Medium (Can be drilled)

Security Tip: Always choose a Welded Grid for residential ground floors. It offers zero give.

Installation Intelligence

Installing a security grid for windows requires precision. Because the unit is a rigid rectangle, your window frame must be perfectly square.

1. Measure Diagonals: If diagonal measurements A and B are not equal, your window is "out of square." You will need a custom-sized grid.
2. Stand-off Mounts: Use 2-inch stand-off brackets to allow for easy window cleaning behind the grid.
3. Tamper-Proofing: Once installed, fill the screw heads with liquid metal or use "break-away" nuts.
